DOMESTIC AND COMMERCIAL HOT WATER SYSTEM

Evo 150-1 Series

Save up to 75% on your hot water costs
Hot water up to 60°C
Air operation range from -5°C to 43°C
Extremely energy efficient
Simple to install
Hydro power booster
Genus control and built-in timer
Vacation mode
Industry leading warranty

Want to Save up to 75%
on your Water Cost?

NEXT EVOLUTION IN WATER HEATING

Conventional water heaters can account for up to 35% of your total energy bill, and contribute significantly to your carbon footprint. When the time comes to replace your water heater, it makes sense to upgrade to a more efficient and environmentally friendly solution to provide your home or business with fast reliable hot water.

Like most other appliances, an increased focus on energy efficiency over the past over the past 20 years has led to significant advancements in hot water systems. So don’t just replace it with what you’ve always had – REPLACE IT WITH SOMETHING BETTER!

The EVO 150-1 is the next evolution in water heating, with advanced energy efficiency technologies and built in smart features to ensure you’re provided with clean, safe, and economical hot water all year round. Unlike traditional hot water systems that use 1kW of energy to produce 1kW of heat, the EVO 150-1 utilises that very same 1kW of energy and heat pump technology to generate 4kW of heat – saving you up to 75% of your hot water costs!

Request a Quote Contact Us

The Evo150-1 will pay for itself within 2 years & save you thousands!

A conventional electric water heater may seem like the cheap option, but will end up costing you thousands of dollars in running costs over the life of the system. Our Evo150-1 hot water system can save you up to 75% on your hot water operating costs thanks to its cutting edge heat pump technology.

Extremely energy efficient
Stable performance from -7 degrees
Reliable, stable hot water
LCD touch screen controller
Simple operation
Intelligent control with built-in timers
Vacation mode

Quiet operation
Hydro-power booster
Auto defrost
Blue diamond enamel coated tank
Horizontal airflow
Easy installation and compact footprint
Ideal to work with solar PV

NEXT EVOLUTION IN WATER HEATING

Extremely Energy Efficient

The Evo 150-1 uses 1kW of energy and heat pump technology to generate 4kW of heat – saving you up to 75% on your hot water costs!

Industry Leading Warranty

Our dedication to reliability is reflected in our Evo150-1 and Evo270-1 models, backed by a 6-year tank warranty and a 5-year warranty on compressors and all parts. This industry leading warranty underscores our commitment to quality, delivering assurance and confidence in the durability of our hot water units.

Compacted Size

The Evo150-1 is nearly 40cm shorter than our larger Evo270-1 unit. The perfect alternative for installations and households with less hot water requirements.

Ideal for Household Applications

With the ability to provide consistent hot water for up to 3 people, the Evo150-1 hot water heat pump perfectly suits installation for small to medium sized households.

Intelligent Built-In Timers

Take control of your hot water with our intelligent built-in timers. Govern when and how long your Evo150-1 operates to make the most of your off-peak energy tariffs or your own created energy via solar PV.

Optional Wi-Fi Control

Control your Evo150-1 anytime, anywhere with the smart Wi-Fi control app (optional upgrade). Available for iOS and Android, the smart phone controller app offers you an easy and convenient way to monitor and control your hot water.

Intelligent Control & Operating Features

Take control of your hot water with our intelligent touch pad and built-in timer.

Our award-winning heat pumps are designed with a number of intelligent operating modes including:

Power boost mode
Eco heating mode
Intelligent mode
High requirement mode
Vacation mode

Vacation Mode

This feature not only allows you to further increase energy efficiency by eliminating unnecessary heating of the system whilst you are away, but you can also program it to reactivate on a specific date to ensure that there is hot water on tap, the moment you walk in the door!

Hydro Power Booster

Get more for your money from your hot water system. The Evo 150-1 can produce up to 66 litres of hot water per hours with our Hydro Power Booster function.

This means a never-ending stream of hot water up to 60°C even when it’s below freezing outside.

Sleek Design & Simple To Install

EVO 150-1 is a stylish compact all in one system, measuring just 568mm in diameter. There are no roof panels, no additional components to assemble on site, and no extra parts or pipes required.

This results in a simple and cost-effective upgrade when installed to the same location as your existing hot water system.

Install Now & Save

Not only will it save you on electricity, the Evo150-1 is also registered with the Australian Federal Government Clean Energy Regulator as an energy efficient water heater.

Once installed, you could also be eligible to receive up to $2,550* towards the costs of your system!

*Actual amounts will vary and will depend on Federal & State Government and state solar rebates.

Ideal to work with solar PV

Complete control over the weather isn’t possible, however complete control over your hot water is with EvoHeat.

Our heat pumps are ideal to work with solar PV! Day or night, rain, hail or shine, our hot water heat pumps will deliver your hot water at your desired temperature with greater efficiency than traditional nd conventional solar hot water heaters – without the need for sunlight and expensive energy bills!

STC'S Available

Climate Zone	Certificates (STCS)
ZONE 1	17 STCS
ZONE 2	17 STCS
ZONE 3	20 STCS
ZONE 4	21 STCS
ZONE 5	21 STCS

Best in the Industry

Nothing out there tops our heating range and here’s why…

Evo heat pumps are tough and durable, built for harsh conditions and utilise cutting edge European components.

With HVAC components from the world’s premier suppliers you can be certain Evo heat pumps are built to perform and keep on performing!

Specifications

Evo150-1 Hot Water Heat Pump Specifications
Storage Capacity	150L
Max Temperature Setting	60°C
Power Input	0.45kW
Heating Output	1.7 kW
Noise Rating	45dB (A)
Running Current	1.88A

Warranty Period

	Tank	Compressor	Parts	On-site Labour
Evo 150-1	6 years	5 years	5 years	1 year

For further peace of mind EvoHeat offer a 6-year warranty on the EVO 150-1 Series tank, 5 years on the compressor & parts, and 1 year on site labour.

EvoHeat have a comprehensive network of specialist service agents nationally to ensure maximum equipment uptime. Spare parts are kept in stock in the extremely unlikely event that they are required.
